MATERIAL THICKNESS CHART
Chart showing Standard Wire Gauge (SWG) sizes with Metric (mm) conversion and the
standardised gauge/mm sizes for our Rivet Bushes.
MATERIAL HARDNESS CROSS-REFERENCE CHART
Chart showing a cross-reference of hardness spome common measurement scales,
including ROCKWELL A, B, C and D, BRINELL, VICKERS and KNOOP.
GALVANIC CORROSION INFORMATION
Galvanic Corrosion is an electrochemical process in which one metal corrodes
preferentially to another when both metals are in electrical contact, in the presence
of an electrolyte. Chart showing the galvanic potential of various materials.
PLATING SPECIFICATIONS
A list of our standard and optional finishes along with the description, performance
and other relevant information for each finish.
MAXIMUM RECOMMENDED TIGHTENING TORQUES FOR METRIC THREADS
A generic guide of maximum recommended tightening torques for metric coarse
threads. These are generic recommendations that should be used as a starting point
only. Special attention should always be taken of any recommendations relating to
the maximum tightening torque in the performance section of our product data.
TECHNICAL RESOURCES & USEFUL INFORMATION
Technical Resources and Useful Information
