Rivet Bushes provide strong reusable threads and threaded spacers in panels too thin to be conventionally tapped.   They can be installed into panels as thin as 0.5mm and do not suffer from the maximum hardness or centreline to edge limitations of self-clinching nuts and standoffs so are suitable for installation into panels of any hardness such as hard stainless steels or in close to edge applications. Rivet Bushes are manufactured to suit a specific panel thickness, however  we can manufacture parts with custom dimensions to suit your particular  application.   Available from stock in metric thread sizes in steel, steel plus electro- plated zinc and stainless steel in round serrated shoulder, round knurled spigot and hexagon styles. We can also supply Unified, BA, BSW and BSP thread sizes subject to minimum order quantities. 316 stainless steel, aluminium and brass rivet bushes are available to order subject to minimum order quantities. Ideally Rivet Bushes should be installed using a press with a suitability profiled punch by applying a parallel squeezing force, however they can be installed using a hammer and ball bearing to form the spigot profile.
RIVET BUSHES
Fastener Insertion Equipment Round Rivet Bush Serrated Shoulder Round Rivet Bush Knurled Spigot Hexagon Rivet Bush Round Rivet Bush Standoff Serrated Shoulder Mini Rivet Bush Serrated Shoulder Mini Rivet Bush Knurled Spigot Round Rivet Bush Standoff Serrated Shoulder Round Rivet Bush Standoff Knurled Spigot Mini Rivet Bush Standoff Serrated Shoulder Mini Rivet Bush Standoff Knurled Spigot Tank Bush Closed End Rivet Bush Panel Thickness Gauge Chart Round Rivet Bush Installed in Panel Round Rivet Bush Installed in Panel Cross Section
