Tooling, Spares, Servicing & Repair
We carry spares for our best selling tools such as jaws and nose cones as
well as other service replaceable items.
Offering support for all the tools we sell, we can service and repair all
our manual and air tooling, as well as other major branded tools such as
Avdel, Gesipa, Emhart, FAR etc. Send us your tool for a quick turnaround,
no obligation, repair or service quotation.
E-500RH
The ELEMENT® range of hand tools was developed with Ergonomics, Ease of
use and Reliability in mind.
All tools come complete with the necessary equipment to change sizes
quickly and easily.
The E-500RH is a compact pistol style tool that is suitable for light assembly
work and can set from Ø2.4 to Ø5.0mm aluminium, steel and stainless steel
blind rivets.
Manufactured from aluminium with ABS plastic grips that are comfortable in
use.
Comes with Ø3.0 - Ø5.0mm nose pieces.
Size: (L) 255mm
Weight: 0.7Kg
E-640RV
E-500RA
The ELEMENT® range of hand tools was developed with Ergonomics, Ease of
use and Reliability in mind.
All tools come complete with the necessary equipment to change sizes
quickly and easily.
The E-640RV is a heavy duty long arm riveter with adjustable levers for easier
setting of large rivets. The adjustable front sleeve, allows the breaking point
to be set in the most ideal position. Suitable for setting from Ø3.0 to
Ø6.4mm aluminium, steel and stainless steel blind rivets.
Manufactured from steel with soft touch plastic grips that are comfortable in
use. It features a plastic mandrel collector that also has a compartment for
holding the nose pieces.
Comes with Ø3.0 - Ø6.4mm nose pieces.
Size: (L) 495mm
Weight: 1.8Kg
The ELEMENT® range of hand tools was developed with Ergonomics, Ease of
use and Reliability in mind.
Suitable for intensive and continuous use, all tools come complete with the
necessary equipment to change sizes quickly and easily.
The E-500RA is a hydraulic/pneumatic blind riveting tool with extraction and
multifunction trigger made for heavy industry environments. Suitable for
setting blind rivets in sizes from Ø2.4 to Ø5.0mm in aluminium, steel and
stainless steel.
Comes with Ø2.4 - Ø5.0mm nose pieces.
Size: 272 x 246 x 99mm
Weight: 1.25Kg
Stroke: 17mm
Operating Pressure: 5 - 7 bar
Power: 7.3kN
E-640RA
The ELEMENT® range of hand tools was developed with Ergonomics, Ease of
use and Reliability in mind.
Suitable for intensive and continuous use, all tools come complete with the
necessary equipment to change sizes quickly and easily.
The E-640RA is a hydraulic/pneumatic blind riveting tool with extraction and
multifunction trigger made for heavy industry environments. Suitable for
setting blind rivets in sizes from Ø4.0 to Ø6.4mm in aluminium, steel and
stainless steel.
Comes with Ø4.8 - Ø6.4mm nose pieces.
Size: 272 x 275 x 120mm
Weight: 1.65Kg
Stroke: 21mm
Operating Pressure: 5 - 7 bar
Power: 12.5kN
E-649RA
The ELEMENT® range of hand tools was developed with Ergonomics, Ease of
use and Reliability in mind.
Suitable for intensive and continuous use, all tools come complete with the
necessary equipment to change sizes quickly and easily.
The E-649RA is a hydraulic/pneumatic blind riveting tool with extraction and
multifunction trigger made for heavy industry environments. Suitable for
setting blind rivets in sizes from Ø4.8 to Ø6.4mm in aluminium, steel and
stainless steel and structural rivets.
Comes with Ø4.8 - Ø6.4mm nose pieces plus a nose piece for structural
rivets.
Size: 292 x 290 x120mm
Weight: 1.95Kg
Stroke: 26mm
Operating Pressure: 5 - 7 bar
Power: 14.5kN
