Installation Method & Performance
Keep-Nut hole preparation Keep-Nut hole gauging Keep-Nut insertion Keep-Nut installed
Prepare hole in base material to correct specification.
Verify hole diameter using Go/No-Go gauge.  Check hole depth against reference line on Go side of gauge.
To ensure correct installation it is recommended that a  threaded mandrel is used. Fully screw on the insert and drive into the hole.
Unscrew the mandrel and the insert is installed and ready for use.
Keep-Nut with bracket
Example assembly
Material
Granite 20mm
Marble 20mm
Travertine 20mm
Fibre cement (high density) 12mm
Fibre cement (high density) 10mm
Fibre cement (high density) 8mm
HPL 12mm
HPL 10mm
HPL 8mm
Corian 12mm
Corian 10mm
Agglomerate stone 15mm
Tempered glass 5mm
Keep-Nut Type
KN4 M6 H8.5
KN4 M6 H8.5
KN4 M6 H8.5
KN4 M6 H8.5
KN4 M6 H8.5
KN2 M6 H6
KN4 M6 H8.5
KN4 M6 H8.5
KN2 M6 H6
KN4 M6 H8.5
KN2 M6 H6
KN4 M6 H8.5
KN1 M4 H5
Average pull-out load on a single insert (Kg)*
490
385
225
275
239
125
541
611
270
484
295
305
75
Comparison of results from tests carried out on a range of materials.
* Tests were carried out under laboratory conditions. Pull-out figures are indicative only and are offered for guidance purposes. It is recommended that you undertake your own tests in the actual application panel material.
With Keep-Nut, radial force is produced only while the insert is under tensile load. With Keep-Nut, the crowns spread the loads into the parent material, allowing large loads to be carried. With Keep-Nut, the thread stops before end of the insert, avoiding extraction as a result of the use of an excessively long bolt. Keep-Nut can carry very high structural loads without the need for resins or adhesives.
Advantages Simple hole preparation Quick installation No need for resins or adhesives Radial force is produced only while the insert is under tensile load. The crowns spread the load into the parent material, allowing large loads to be carried Thread stops before end of insert, avoiding extraction as a result of the use of an excessively long bolt
Material & Finish
Bush: Stainless Steel Crown: Stainless Steel Body: Plastic
Part Number Examples
Part number is made up as follows: (Type code) (Thread code) (Height code) (Thread Length) For example: KN2 M4 H6 20 (Keep-Nut Flanged 2 crowns M4 6mm height 20mm long) KN4 M6 H8.5 25 (Keep-Nut Flanged 4 crowns M6 8.5mm height 25mm long) KN4 M8 H15 30 (Keep-Nut Flanged 4 crowns M8 15mm height 30mm long)
RoHS REACH COMPLIANT
Dimensional
M4
KN2 M* H6 **
M5
KN4 M* H8.5 **
M6
M4
8.5
M8
Special order as required
M5
M8
11.0
M6
KN4 M* H15 **
M6
M8
17.5
Info
Keep-Nut® Stud is a press-in threaded insert that utilises a mechanical anchoring feature, to provide permanent threads in panels made of marble, granite or other stones, as well as composites, carbon, Corian®, HPL, glass and others solid surface materials. Keep-Nut Stud is manufactured in stainless steel and consists of a male thread , a set of toothed spring washers (crowns), and a plastic ring holding the parts together. Available to special order in thread and body lengths to suit your specific application, Keep-Nut Studs can be installed quickly since the user simply needs to drill the material with the correct hole diameter and press-in the insert. Keep-Nut Studs can be customised with different versions and sizes, to meet specific customer requirements. The Keep-Nut insert is specifically developed to fasten ventilated façades, wall-coverings, décor and interiors, furniture, kitchen and sanitary elements, as well as a variety of other applications. Keep-Nut inserts have several advantages compared to other fasteners for stone and solid materials. The preparation needed is just a cylindrical hole – an undercut hole is not required – which means that standard tools can be used. In addition, assembly by pressure is quick and easy and does not require use of any additional resins or adhesives. Keep-Nut inserts can be used for hidden assemblies without any protruding parts, facilitating the handling and installation of a variety of materials. In use, the crowns are engaged by axial force, acting radially against the hole wall, effectively permanently locking the insert in place. Keep-Nut is a trademark of SPECIALINSERT S.r.l., Corian is a trademark of E. I. du Pont de Nemours and Company.
Keep-Nut Stud
(Type) (Thread) (Height Code) (Length)
D1 Thread
S Min. Thickness**
L1 Thread Length
D2 Hole Ø ±0.2
12
12
12
6.5
9.0
15.5
L2 Hole Depth +1.0
No. of Crowns
2
4
4
Installation Force (kN)*
0.4
1.0
1.0
Pull-Out Force (kN)*
2.5
3.5
4.2
*Figures are indicative only and are offered for guidance purposes. ** Minimum material thickness is related to parent material characteristics. It is recommended that you undertake your own tests in the actual application panel material.
TYPE KN
KEEP-NUT® STUD
